The DKT500A 19-30 is a high-performance phase control thyristor designed for large power converters, DC and AC switches, and both active and passive inverters. This thyristor features a center amplifying gate and a durable metal case with ceramic insulation to ensure efficient and reliable performance. With an average on-state current of 500A, a surge current capability of up to 10kA, and a voltage range of 1900V to 3000V, the DKT500A 19-30 is ideal for high-power applications that require efficient energy conversion and surge protection.
Features
Center amplifying gate design: Ensures precise and efficient switching.
Metal case with ceramic insulator: Provides excellent insulation and thermal management.
Low on-state voltage drop and switching losses: Improves overall system efficiency.
Surge current capability: Can handle up to 10kA of surge current, perfect for large power systems.
Voltage range: Rated for a repetitive peak reverse voltage between 1900V and 3000V.
High current capacity: Capable of handling 500A of average on-state current.
Built-in protection: Features under-voltage, short-circuit, and over-temperature protection.
Applications
Large Power Converters: Ideal for high-efficiency power conversion in industrial applications.
DC and AC Switches: Suitable for controlling high-power electrical circuits.
Active and Passive Inverters: Used in both active and passive inverter circuits for motor control and energy conversion.
Surge Protection: Provides protection against surge currents, ensuring safe and reliable operation in power systems.
